Hydraulic Tyre Curing Press
Solid Tyre Curing Press
Hydraulic curing presses for solid tyres come in side-plate, frame-type, and four-column structures for different production setups.
Technical Specifications
| Model | ||||
| Mold Closing Force | 400Tons | 600Tons | 800Tons | 1500Tons |
| Platen Size (L × W) | 800x800mm | 1000x1000mm | 1250x1250mm | 2000x2000mm |
| Number of Cavities | 1/2/3/4 | 1/2/3/4 | 1/2 | 1 |
| Daylight | 360mm | 400mm | 460mm | 1200mm |
| Heating Method | Steam/Electric | Steam/Electric | Steam/Electric | Steam/Electric |
| Ram Diameter | Ø 550mm | Ø 650mm | Ø 750mm | Ø1000mm |
| Fast Mold Closing Speed | ≥20mm/s | ≥20mm/s | ≥20mm/s | ≥20mm/s |
| Slow Mold Closing Speed | ≥1-3mm/s | ≥1-3mm/s | ≥1-3mm/s | ≥1-3mm/s |
